DAF Dissolved Air Flotation For Textile And Leather Factory Sewage Treatment Plant
Description
Dissolved Air Flotation is water treatment process that clarifies wastewaters (or other waters)
by the removal of suspended matter such as oil or solids. The removal is achieved by
dissolving air in the water or wastewater under pressure and then releasing the air at
atmospheric pressure in a flotation tank basin. The released air forms tiny bubbles which
adhere to the suspended matter causing the suspended matter to float to the surface of the
water where it may then be removed by a skimming device.
Application
1. Abattoirs, meat and poultry wastewater treatment
2. Brewery, winery and soft drink manufacture wastewater treatment
3. Baking and confectionery, ready meals and vegetable production and packaging
manufactures wastewater treatment
4. Commercial laundry wastewater treatment
5. Cosmetics manufactures production and packaging wastewater treatment
6. Dairy inc milk, cream, yoghurt and cheese processing and packaging wastewater treatment
7. Fish processing wastewater treatment
8. Paper mills wastewater treatment
9. Petrochemical wastewater treatment
10. Pharmaceutical wastewater treatment
11. Textile manufacture wastewater treatment
Advantage
(1) Long-term & stable performance, easy operation, easy maintenance, low noise;
(2) Micro bubbles and high adsorption of suspended particles to improve the SS removal
effect; Micro bubble size 10-30 microns
(3) Automatic control and easy maintenance
(4) Multiphase pump can replace the pump, air compressor, large tanks, jet, and the release
of the first class;
(5) Dissolved air water dissolving efficiency is 80-100%, three times higher efficiency than
traditional dissolved air flotation;
(6) dissolved air flotation machine to inhale, over the suction pump pressure within the mixing,
gas-liquid dissolving efficiency is high, the micro air bubble 20 microns or less;
(7) multilayer mud, ensure water effect;
(8) low voltage operation, the efficiency of dissolved air is as high as 99%, outgassing rate as
high as 99%.
(9) Overcome the touch device operation is not stable, large bubbles churning and release the
head congestion
Technical parameters
| Model | Capacity(m3/h) | Dissolved Air Water Volume (m3/h) | Main Motor Power(KW) | Scraper Power(KW) | Air Compressor Power(KW) | Dimension (mm) |
| HLDAF-5 | 4-5 | 2 | 3 | 0.55 | 0.75 | 2800*2100*2200 |
| HLDAF-10 | 8-10 | 3.5 | 3 | 0.55 | 0.75 | 3700*2100*2200 |
| HLDAF-15 | 10-15 | 5 | 4 | 0.55 | 1.5 | 4500*2200*2300 |
| HLDAF-20 | 15-20 | 8 | 5.5 | 0.55 | 1.5 | 4650*2400*2300 |
| HLDAF-30 | 20-30 | 10 | 5.5 | 0.75 | 1.5 | 5840*2700*2300 |
| HLDAF-40 | 35-40 | 15 | 7.5 | 0.75 | 1.5 | 6800*2700*2300 |
| HLDAF-50 | 45-50 | 25 | 7.5 | 0.75 | 2.2 | 7500*2900*2300 |
| HLDAF-60 | 55-60 | 25 | 7.5 | 1.1 | 2.2 | 8500*2900*2300 |
| HLDAF-70 | 65-70 | 30 | 15 | 1.1 | 2.2 | 9000*2900*2300 |
| HLDAF-80 | 75-80 | 30 | 15 | 1.1 | 2.2 | 9300*3500*2300 |
| HLDAF-100 | 95-100 | 50 | 15 | 1.1 | 3 | 117500*3750*2300 |
| HLDAF-150 | 140-150 | 50 | 15 | 1.5 | 3 | 12100*3750*2300 |
| HLDAF-200 | 190-200 | 80-100 | 22 | 1.5 | 3 | 12400*3750*2860 |
| HLDAF-250 | 240-250 | 100 | 22 | 1.5 | 3 | 14700*3750*2860 |
| HLDAF-300 | 280-300 | 100 | 22 | 1.5 | 3 | 19100*3750*3150 |
